PVC Type I Dark Gray Sheet - Chemical Resistant & High Impact PVC Sheet
PVC Type I Dark Gray Sheet - Chemical Resistant & High Impact PVC Sheet
SKU:SHA-f3904e
High-impact PVC Type I Dark Gray Sheet with exceptional corrosion resistance, ideal for demanding applications. Meets ASTM standards.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
PVC Type I Dark Gray Sheet - Chemical Resistant & High Impact PVC Sheet
$49.99
Quantity: 1
Claim Your Seller Account
PVC Type I Dark Gray Sheet - Chemical Resistant & High Impact PVC Sheet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVC Type I Dark Gray Sheet is a high-quality material known for its exceptional chemical resistance, making it ideal for applications requiring maximum corrosion resistance. This PVC sheet offers excellent tensile strength, flexural strength, and mechanical properties. With a maximum service temperature of 140°F, it meets ASTM D1784, CLASS 12454-B and L94 V0 standards. Fabricated using advanced techniques, this sheet is available in various sizes to suit different requirements.
Product Specifications
Specifications Density Astm D792
1.42 gm/cc
Specifications Dielectric Strength Astm D149
544 V/mil
Specifications Flame Spread E84
15
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus
481000 psi
Specifications Flexural Strength
12800 psi
Specifications Hardness Durometer Shore D
89
Specifications Hardness Rockwell Astm D785
R115
Specifications Heat Deflection Temperature 264 Psi
179 ºF
Specifications Izod Impact Strength Astm D256
1 ft·lb/in
Specifications Optional Sheet Size
12 x 24 | 12 x 36 | 24 x 120 | 24 x 24 | 24 x 96 | 36 x 48 | 48 x 48 | 48 x 72 | 60 x 120
Specifications Sheet Size
12 x 12 in
Specifications Tensile Modulus Astm D638
411000 psi
Specifications Tensile Strength Astm D638
7500 psi
Specifications Thickness
5.000 in
Specifications Vicat Softening Point Astm D1525
181 ºF
Specifications Water Absorption 24 Hrs 73f Astm D570
0.06 %
Specifications Weight
37.50 lb/ft²
