PVDF Gauge Isolator with All Stainless 2.5" Gauge
PVDF Gauge Isolator with All Stainless 2.5" Gauge
SKU:GAU-a2a649
Get precise pressure isolation with the PVDF Gauge Isolator & All Stainless 2.5" Gauge. Ideal for accurate media transmission.
Regular price
$412.95
Regular price
Sale price
$412.95
Unit price
per
Initiate Order
PVDF Gauge Isolator with All Stainless 2.5" Gauge
$412.95
Quantity: 1
Claim Your Seller Account
PVDF Gauge Isolator with All Stainless 2.5" Gauge
$412.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVDF Gauge Isolator with Viton Diaphragm provides top-notch protection and isolation for pressure sensing instruments. With a 1/2" Female NPT Inlet Connection and an All Stainless 0-30" Hg Vacuum Ashcroft Gauge, this isolator ensures accurate pressure transmission and optimal containment. Its low profile design eliminates dead volume and its convoluted diaphragm guarantees precision. Compliant with ANSI Schedule 120 standards, this isolator is a reliable choice for institutional and government procurement.
Product Specifications
Features 0
Protects and isolates pressure sensing instruments Total isolation from system media Low profile design eliminates dead volume Convoluted diaphragm allows accurate transmission of system pressure Optimum pressure containment spherical design Low in original cost and maintenance Simple installation
Materials Of Construction 0
Body: PVC: Polyvinyl Chloride CPVC: Chlorinated Polyvinyl Chloride PP: Polypropylene homopolymer, glass & mineral reinforced Membrane: Standard: PTFE®, also available in: FPM: Viton®, Fluorine elastomer EPDM: Ethylene Propylene elastomer
Scope 0
The Marquest Gauge Isolator provides two fluid chambers separated by an impermeable membrane. The upper chamber (instrument side) is normally filled with a stabilized liquid. The lower chamber receives the media under pressure. Most pressure sensing devices are compatible with 1/4" FNPT outlet. The inlet is standard 1/2" FNPT or 1/4" FNPT. Chemical resistance and purity levels are as recommended for the base materials. No metals or lubricants are used in construction, internally or externally. Custom membranes may be supplied upon request.
Specifications Inlet Connection
1/2" Female NPT
Specifications Installed Gauge
0-30 in-Hg, All Stainless
Specifications List Price
412.95 USD
Specifications Materials
PVDF, Viton Diaphragm
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
