PVDF Mini Tuff Gauge Isolator with Wika 212.53 Gauge, 1/4
PVDF Mini Tuff Gauge Isolator with Wika 212.53 Gauge, 1/4
SKU:GAU-956e62
PVDF Mini Tuff Guard Isolator, 1/4" Inlet Male NPT, Composite PTFE/FKM Diaphragm, w/ 0-60 PSI Wika 212.53 Stainless Case/Brass Internals 2.5" Dia. Gauge, Glycer
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
PVDF Mini Tuff Gauge Isolator with Wika 212.53 Gauge, 1/4
$49.99
Quantity: 1
Claim Your Seller Account
PVDF Mini Tuff Gauge Isolator with Wika 212.53 Gauge, 1/4
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Features & Benefits: Provides a compatible, protective barrier between process fluids and instruments Adds system reliability by eliminating instrument failures All injection molded, rugged design and construction Ultra compact size for limited space applications Extremely low cost for O.E.M. integration Replaceable diaphragm Integral wrench provisionsDiaphragm safety featuresSelf Venting, 1/4" female NPT instrument connection. Zero pressure build when installing instrument Instrument Connection: 1/4" Female NPT Venting Thread, with Viton O-Ring Instrument SealGauge Style: Wika 212.53 Stainless Case/Brass Internals 2.5" Dia. Gauge, Glycerin Filled Case. 2.5% Accuracy Full Span, 0-60 PSIProcess/Inlet Connection: 1/4" Male NPT Max Pressure Ratings: PVDF: 250 PSI @ 72° Fahrenheit Materials of Construction: Upper & Lower Body: Injection molded in Solef High Purity PVDF. FDA, USDA, and USP standards are either met and/or exceeded, please contact us for further validation. Diaphragm: Composite Diaphragm PTFE/FKM. Wetted side is Virgin PTFE. Non-wetted side is FKM.Assembly Internals Fill: 70% Glycerin(99.5% FDA Approved), 30% Distilled Water Mix (Silicone, Halocarbon Fills Available
Product Specifications
Specifications Inlet Connection
1/4" MNPT
Specifications Installed Gauge
0-60 PSI, Stainless/Brass
Specifications List Price
143.5 USD
Specifications Materials
PVDF, PTFE/FKM Diaph
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
