PVDF Mini Tuff Guard Isolator with 2.5" Ashcroft 1008s Gauge
PVDF Mini Tuff Guard Isolator with 2.5" Ashcroft 1008s Gauge
SKU:GAU-5bf359
Ensure precise pressure monitoring with our PVDF Mini Tuff Guard Isolator pre-fitted with Ashcroft 1008s Gauge. Compliance with FDA, USDA, USP.
Regular price
$229.50
Regular price
Sale price
$229.50
Unit price
per
Initiate Order
PVDF Mini Tuff Guard Isolator with 2.5" Ashcroft 1008s Gauge
$229.50
Quantity: 1
Claim Your Seller Account
PVDF Mini Tuff Guard Isolator with 2.5" Ashcroft 1008s Gauge
$229.50
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVDF Mini Tuff Guard Isolator with PTFE/FKM diaphragm and a 0-100 PSI All Stainless Ashcroft 1008s Gauge ensures accurate pressure monitoring with 2.5% full span accuracy. Compliant with FDA, USDA, and USP standards, this durable assembly offers a protective barrier, compact design, and easy installation, making it cost-effective for OEM integration. With 1/4" MNPT inlet connection and glycerin-filled case for vibration protection, this diaphragm seal assembly is designed for longevity in demanding environments.
Product Specifications
Specifications Inlet Connection
1/4" MNPT
Specifications Installed Gauge
0-100 PSI, All Stainless
Specifications List Price
229.50 USD
Specifications Materials
PVDF, PTFE/FKM Diaph
Specifications Shipping Note
We will let you know the shipping charges once we receive the order
