PVDF Mini Tuff Guard Isolator with 2" Economy Gauge
PVDF Mini Tuff Guard Isolator with 2" Economy Gauge
SKU:GAU-4510ae
Enhance system reliability with PVDF Mini Tuff Guard Isolator featuring FDA-compliant materials & an accurate 2" Economy Gauge (0-200 PSI).
Regular price
$116.50
Regular price
Sale price
$116.50
Unit price
per
Initiate Order
PVDF Mini Tuff Guard Isolator with 2" Economy Gauge
$116.50
Quantity: 1
Claim Your Seller Account
PVDF Mini Tuff Guard Isolator with 2" Economy Gauge
$116.50
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVDF Mini Tuff Guard Isolator features a rugged design with an injection-molded PVDF body that meets FDA, USDA, and USP standards. It enhances system reliability by safeguarding instruments from process fluids, preventing failures. This isolator boasts an ultra-compact size for space-limited applications and a replaceable diaphragm for cost-effective maintenance. With a Viton O-Ring seal and self-venting 1/4" female NPT instrument connection, it ensures zero pressure build-up during installation. The included 2" Economy Gauge with a black painted steel case and brass internals offers precise measurements up to 200 PSI.
Product Specifications
Specifications Inlet Connection
1/4" MNPT
Specifications Installed Gauge
0-200 PSI, Brass, Blk Pntd Steel
Specifications List Price
116.5 USD
Specifications Materials
PVDF, PTFE/FKM Diaph
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
