The RB82516 Series PVDF Plastic Inline Connector Fitting is designed for precise orifice and filter integration in flexible tube systems. Crafted from high-quality PVDF material, this fitting ensures reliable performance with an inner diameter of 0.0070 inch (I.D.) and an outer diameter of 0.030 inch (O.D.). Featuring a sharp edge ruby straight-hole orifice, this fitting guarantees low flow, accuracy, and repeatability, making it ideal for applications requiring utmost precision. With suggested pressure ranges varying from low to high, this connector is versatile and adaptable to different operational needs.
Product Specifications
Additional Information Additional Information
This connector comes with a unique sharp edge ruby orifice series in sizes from 0.0020" thru 0.0130".This Sharp Edge Ruby Orifice series is laser drilled and wire lapped to insure Roundness, surface finish and sharp edges.This orifice series is a good choice where the designer requires low flow, accuracy and repeatability.
Specifications Diameter
0.062 in
Specifications Inside Tubing Diameter
1/16 in
Specifications Material
Plastic
Specifications Orifice Inner Diameter Id
0.0070 in
Specifications Orifice Outer Diameter Od
0.030 in
Specifications Orifice Style
Sharp Edge Ruby Straight-Hole
Specifications Product Style
Inline Connector for Flexible Tube to Tube
Specifications Product Type
Orifice Connectors Fittings
Specifications Series
RB82516
Specifications Suggested Pressures
0.060 O.D. - Low Pressure (Under 150 psi) | 0.118 O.D. - Medium Pressure (5000 psi or lower) | 0.087 O.D. - High Pressure (Above 5000 psi)
