PVDF True Union Ball Valve - 1/2" with FPM O-rings and Socket Fusion End Connections
PVDF True Union Ball Valve - 1/2" with FPM O-rings and Socket Fusion End Connections
SKU:TRU-894b6f
Durable PVDF True Union Ball Valve for precise flow control in various applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
PVDF True Union Ball Valve - 1/2" with FPM O-rings and Socket Fusion End Connections
$29.99
Quantity: 1
Claim Your Seller Account
PVDF True Union Ball Valve - 1/2" with FPM O-rings and Socket Fusion End Connections
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVDF True Union Ball Valve from our TB Series combines durability and versatility for a wide range of applications. Constructed with PVDF body material and FPM seals, it ensures reliable performance in various environments. Featuring IPS socket fusion end connections, this valve offers easy installation and a secure fit. With a pressure rating of 150 psi, Cv coefficient of 8.0, and bi-directional flow configuration, this valve excels in delivering precise flow control. Whether for residential, commercial, or institutional use, this ball valve meets stringent quality standards and promises long-lasting functionality.
Product Specifications
Dimensional Attributes A
4.65 in | 118.11 mm
Dimensional Attributes B
0.49 in | 12.45 mm
Dimensional Attributes C
2.23 in | 56.64 mm
Dimensional Attributes D1
2.80 in | 71.12 mm
Dimensional Attributes D2
2.62 in | 66.55 mm
Dimensional Attributes H
2.82 in | 71.63 mm
Specifications Body Material
PVDF
Specifications Cv Coefficient
8.0
Specifications End Connection
Socket Fusion
Specifications Flow Configuration
Bi-directional
Specifications Pressure Rating Non Shock
150 psi/ 10 bar
Specifications Seals
FPM
Specifications Series
TB
Specifications Size
1/2"
Specifications Weight
0.75 lb | 0.34 kg
