PVDF True Union Ball Valve - 1" with FPM O-rings & Socket Fusion End
PVDF True Union Ball Valve - 1" with FPM O-rings & Socket Fusion End
SKU:TRU-938483
Durable PVDF Ball Valve with FPM O-rings & Socket Fusion End, ideal for precise flow control in demanding environments.
Regular price
$54.99
Regular price
Sale price
$54.99
Unit price
per
Initiate Order
PVDF True Union Ball Valve - 1" with FPM O-rings & Socket Fusion End
$54.99
Quantity: 1
Claim Your Seller Account
PVDF True Union Ball Valve - 1" with FPM O-rings & Socket Fusion End
$54.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVDF True Union Ball Valve from the TB Series is designed for durability and reliability. Built with PVDF material, FPM O-rings, and Socket Fusion end connections, this valve ensures excellent chemical resistance and leakage prevention. With a pressure rating of 150 psi, Cv Coefficient of 29.0, and bi-directional flow configuration, it offers optimal performance for a wide range of applications. Meeting stringent standards, this valve is an ideal choice for industries requiring precision and quality.
Product Specifications
Dimensional Attributes A
5.33 in | 135.38 mm
Dimensional Attributes B
0.93 in | 23.62 mm
Dimensional Attributes C
2.98 in | 75.69 mm
Dimensional Attributes D1
3.31 in | 84.07 mm
Dimensional Attributes D2
3.10 in | 78.74 mm
Dimensional Attributes H
3.24 in | 82.30 mm
Specifications Body Material
PVDF
Specifications Cv Coefficient
29.0
Specifications End Connection
Socket Fusion
Specifications Flow Configuration
Bi-directional
Specifications Pressure Rating Non Shock
150 psi/ 10 bar
Specifications Seals
FPM
Specifications Series
TB
Specifications Size
1"
Specifications Weight
1.15 lb | 0.52 kg
