PVDF True Union Ball Valve 1" with FPM O-rings & Threaded End
PVDF True Union Ball Valve 1" with FPM O-rings & Threaded End
SKU:TRU-e442b0
Premium PVDF True Union Ball Valve for superior chemical resistance and reliable performance. Bi-directional flow with 150 psi rating.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
PVDF True Union Ball Valve 1" with FPM O-rings & Threaded End
$49.99
Quantity: 1
Claim Your Seller Account
PVDF True Union Ball Valve 1" with FPM O-rings & Threaded End
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVDF True Union Ball Valve from the TB Series offers superior chemical resistance and durability. Constructed with PVDF body material and FPM seals, this valve ensures reliable performance in demanding environments. Featuring threaded end connections and a pressure rating of 150 psi, it facilitates bi-directional flow with a Cv Coefficient of 29.0. Ideal for sizes 1/2"-4", this valve meets stringent industry standards for quality and performance.
Product Specifications
Dimensional Attributes A
5.33 in | 135.38 mm
Dimensional Attributes B
0.93 in | 23.62 mm
Dimensional Attributes C
2.98 in | 75.69 mm
Dimensional Attributes D1
3.31 in | 84.07 mm
Dimensional Attributes D2
3.10 in | 78.74 mm
Dimensional Attributes H
3.24 in | 82.30 mm
Specifications Body Material
PVDF
Specifications Cv Coefficient
29.0
Specifications End Connection
Threaded
Specifications Flow Configuration
Bi-directional
Specifications Pressure Rating Non Shock
150 psi/ 10 bar
Specifications Seals
FPM
Specifications Series
TB
Specifications Size
1"
Specifications Weight
1.15 lb | 0.52 kg
