Quad 32-Bit Quadrature Decoder Module with Optical Isolation
Quad 32-Bit Quadrature Decoder Module with Optical Isolation
SKU:INT-fe45e3
Highly reliable Quad 32-Bit Quadrature Decoder with noise reduction filters and 12V isolated power inputs for efficient signal processing.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Quad 32-Bit Quadrature Decoder Module with Optical Isolation
$349.99
Quantity: 1
Claim Your Seller Account
Quad 32-Bit Quadrature Decoder Module with Optical Isolation
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Quad 32-Bit Quadrature Decoder Module offers four independent 32-bit channels with optic isolated inputs and noise reduction filters, ideal for use with quadrature encoders. Each channel features optical isolation for precise
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Accuracy Count Accuracy
±1 count
Digital Inputs Optic Isolated Frequency Digital Inputs Optic Iso
DC to 1 MHz
Digital Inputs Optic Isolated Isolation
300 V
Digital Inputs Optic Isolated Level Digital Inputs Optic Isolate
Requires 5 Volts at 8 mA to trigger the optic coupled input. Inputs are protected to ±50 Volts.
General Connectors
50-pin, Type D. Connector is mounted on the front and the mate is supplied.
General Mounting
Occupies one slot in Series 6000 enclosures.
General Temperature
0 to +50 ºC
Isolated Power Current
1 Amp maximum.
Isolated Power Voltage
12 V
Ordering Information Ordering Information
6049 - 4-Channel, 32-bit Quadrature Decoder Module.
Outputs Resolution
32-bits
Overview Measurement Type
Encoder
Range Count Range
0 to 4.295 x 109 or ± 2.147 x 109
Range Frequency Range
0 Hz to 1 MHz
