Quartz Fused Sputtering Target - 6mm Thickness, 50-75mm Diameter
Quartz Fused Sputtering Target - 6mm Thickness, 50-75mm Diameter
SKU:QUA-f2b290
High-purity Quartz (SiO2) Fused Sputtering Target for precise sputtering processes, exceptional chemical resistance & superior electrical/mechanical properties.
Regular price
$499.99
Regular price
Sale price
$499.99
Unit price
per
Initiate Order
Quartz Fused Sputtering Target - 6mm Thickness, 50-75mm Diameter
$499.99
Quantity: 1
Claim Your Seller Account
Quartz Fused Sputtering Target - 6mm Thickness, 50-75mm Diameter
$499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Quartz (SiO2) Fused Sputtering Target boasts high purity (99.0%) suitable for sputtering processes. With excellent chemical resistance to acids, alkalis, and halogens, it offers superior electrical and mechanical properties. Its precise dimensions, thermal stability, and optical transparency make it ideal for optical and semiconductor applications. Ready for immediate shipment or customization, this target meets stringent industry standards for performance and reliability.
Product Specifications
Chemical Resistance Alkalis
Fair
Chemical Resistance Concentrated Acids
Good
Chemical Resistance Dilute Acids
Good
Chemical Resistance Halogens
Good
Chemical Resistance Metals
Fair
Electrical Properties Dielectric Constant
3.8
Electrical Properties Dielectric Strength
25.0 to 40.0 kV mm-1
Electrical Properties Volume Resistivity At 25 Degree Celsius C
1018 µΩ·cm
Material Material
Quartz FusedSilicone dioxide occurs naturally as sand or rock and when melted, the resulting product is called Fused Quartz. If the silicone dioxide is synthetically derived, the material is often called Fused Silica. Fused Quartz is very pure, has a high chemical resistance, good thermal shock resistance and is very strong in compression. The low thermal expansion coefficient makes it ideal for mirrors and optical flats. It is used for viewing windows, being transparent to wavelengths from around 0.2 to 3.5 µm, insulators for electronic applications and for semi-conductor manufacturing.
Mechanical Properties Hardness Knoop
820 Kgf mm-2
Mechanical Properties Hardness Vickers
1000 Kgf mm-2
Mechanical Properties Shear Strength
70 MPa
Mechanical Properties Tensile Modulus
72.00 to 74.00 GPa
Mechanical Properties Tensile Strength
48.00 MPa
Note Note
These targets are normally available for immediate shipment from stock. Other sizes are available to special order.
Physical Properties Apparent Porosity
0.00 %
Physical Properties Density
2.200 g·cm-3
Physical Properties Refractive Index
1.460
Physical Properties Useful Optical Transmission Range
180 to 2500 nm
Physical Properties Water Absorption Saturation
0 %
Pultrusion Compressive Strength
1100 MPa
Specifications Diameter
50 to 75 mm
Specifications Purity
99.0 %
Specifications Thickness
6 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
0.540 x10-6 K-1
Thermal Properties Melting Point
1715.00 ºC
Thermal Properties Specific Heat At 25 Degree Celsius C Temperat
670.0 to 740.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 20 Degree Celsius C T
1.46 W m-1K-1
Thermal Properties Upper Continuous Use Temperature
1100 to 1400 ºC
Tolerances Disc Diameter Tolerance
0.5 mm
Tolerances Thickness Tolerance
0.5 mm
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
