Radius U-Bend Pads - Green 80A, 35% Deflection
Radius U-Bend Pads - Green 80A, 35% Deflection
SKU:SQU-292ffc
Achieve 180-degree bends effortlessly with Radius U-Bend Pads. Green 80A duro, 35% deflection.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Radius U-Bend Pads - Green 80A, 35% Deflection
$49.99
Quantity: 1
Claim Your Seller Account
Radius U-Bend Pads - Green 80A, 35% Deflection
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Radius U-Bend Pads (PUD-112-80A) are specially engineered square and rectangular shaped pads with a molded U-shaped top surface, allowing for seamless 180-degree U-bends in a single operation. Designed to perfectly fit standard ASTM Steel C-Channels, these pads serve as efficient holders and retainers, offering reliability and durability. With multiple deflections and a hardness of 80A duro, these pads provide optimal performance. The Pad Width is 2.25 inches, Pad Height 2.25 inches, Hole Diameter 1.50 inches, and Gauge Capacity for 90-V is 16 ga. Accommodating a Size for U 180-Radius of 3/8 inches, they are compatible with Retainer Part Number CR2222.
Product Specifications
Specifications Color
Green
Specifications Deflections
35 %
Specifications Gauge Capacity Fo 90 V
16 ga
Specifications Hardness
80A duro
Specifications Hole Diameter
1.50 in
Specifications Number Of Forming Surfaces
1
Specifications Pad Height
2.25 in
Specifications Pad Width
2.25 in
Specifications Retainer Part Number
CR2222
Specifications Size For U 180 Radius
3/8 in
