Red 3-Pin Wire Mount Socket Connector
Red 3-Pin Wire Mount Socket Connector
SKU:PRO-a8cd10
Reliable Red 3-Pin Wire Mount Socket Connector for secure wire connections in 26-24 AWG sizes. Compliant with industry standards.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Red 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
Red 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Red 3-Pin Wire Mount Socket Connector is a high-quality sensor connector designed for maximum alternating current/direct current voltage of ~250V. Made with C5210 gold-plated terminals and polycarbonate/ABS body material, this connector ensures reliable performance and durability. With a rated current of 3.0A and compliant with industry standards, it offers secure wire connections within the 26-24 AWG wire size range. Suitable for institutional and government applications.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Red
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Red
Specifications Cover Diameter
0.8 to 1.0 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.13 to 0.21 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.13 to 0.21 mm²
Specifications Wire Size
26-24 AWG
