Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Panel-Mounted Valve

Name: Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Panel-Mounted Valve
Brand: Distributor To Industry, Inc.
SKU: DRI-8c2df5
Price: 129.99 USD
Availability: OutOfStock

SKU:DRI-8c2df5

Versatile and durable Triple 3-Way Panel-Mounted Valve for precise directional control in deluxe panel installations.

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Panel-Mounted Valve offers exceptional versatility and durability for deluxe panel installations. Featuring a streamlined design, it is perfect for both horizontal and vertical mounting, with internal parts sealed for outdoor use. The valves provide multiple positions of operation, with features like solid steel shaft, bronze bearings, and Nylatron plastic detents for enhanced strength and longevity. Ideal for multi-position cylinders and various supply pressure applications, this valve ensures precise directional control for up to four circuits.

Product Specifications

Features Features

Several new features have been designed into the Panel-Mounted "A" PILOTAIR Valve for added strength, easier maintenance and longer service life.One-piece solid steel shaft for increased strength.Bronze bearings in cam housing for longer wear.Separate steel handle and hub for increased strength.Tooth-type Nylatron plastic detents for longer wear and more positive detenting.Internal centering spring assembly for longer wear and more positive handle centering.Die-cast anodized aluminum body and cam housing for lighter weight, added strength and corrosion resistance.More-positive handle latch. Available in one, two, and three positions for added flexibility and longer service lift.

Specifications Handle Positions

Specifications Height

7 23/32 in.

Specifications Length

6 5/16 in.

Specifications Model

2-HA-3

Specifications Old Part

P 062269 | P -062269-00000 | P 62269 | P062269 | P62269

Specifications Type

Triple 3-Way Valve

Specifications Weight

4 lb | 1.81 kg

Specifications Width

3 3/4 in.

Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Panel-Mounted Valve
