Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Valve Panel-Mounted PILOTAIR

Name: Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Valve Panel-Mounted PILOTAIR
Brand: Distributor To Industry, Inc.
SKU: DRI-a7080c
Price: 189.99 USD
Availability: OutOfStock

SKU:DRI-a7080c

Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Valve Panel-Mounted PILOTAIR - High durability and versatile control for demanding applications.

$189.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Valve Panel-Mounted PILOTAIR is a high-performance pneumatic directional control valve suitable for deluxe panel mountings. With a streamlined compact design and robust features like a one-piece solid steel shaft, bronze bearings, and tooth-type Nylatron plastic detents, this valve ensures durability and ease of maintenance. Ideal for outdoor installations, it offers operating versatility with up to five handle positions and various control configurations. Designed for transmission controls and multiposition cylinders, it meets diverse application requirements and provides reliable performance under demanding conditions.

Product Specifications

Features Features

Several new features have been designed into the Panel-Mounted "A" PILOTAIR Valve for added strength, easier maintenance and longer service life.One-piece solid steel shaft for increased strength.Bronze bearings in cam housing for longer wear.Separate steel handle and hub for increased strength.Tooth-type Nylatron plastic detents for longer wear and more positive detenting.Internal centering spring assembly for longer wear and more positive handle centering.Die-cast anodized aluminum body and cam housing for lighter weight, added strength and corrosion resistance.More-positive handle latch. Available in one, two, and three positions for added flexibility and longer service lift.

Specifications Handle Positions

Specifications Height

7 23/32 in.

Specifications Length

6 5/16 in.

Specifications Model

2-HA-3

Specifications Old Part

P 060877 | P -060877-00000 | P 60877 | P060877 | P60877

Specifications Type

Triple 3-Way Valve

Specifications Weight

4 lb | 1.81 kg

Specifications Width

3 3/4 in.

Rexroth 2-HA-3 & 2-HA-4 Triple 3-Way Valve Panel-Mounted PILOTAIR
