Rexroth Plastic Quick Exhaust Valve (Imperial, 1/4 Inch, In-Line)
Rexroth Plastic Quick Exhaust Valve (Imperial, 1/4 Inch, In-Line)
SKU:DRI-49cd10
Enhance air control in drilling rigs with the Rexroth Plastic Quick Exhaust Valve. Durable, efficient, and industry-compatible.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Rexroth Plastic Quick Exhaust Valve (Imperial, 1/4 Inch, In-Line)
$39.99
Quantity: 1
Claim Your Seller Account
Rexroth Plastic Quick Exhaust Valve (Imperial, 1/4 Inch, In-Line)
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Rexroth Plastic Quick Exhaust Valve (Imperial, 1/4 Inch, In-Line) is a reliable solution designed for drilling rig air systems in marine, mobile, and oil field applications. With a maximum working pressure of 150 psi and a temperature range from -20 to 160 °F (200 °F intermittent), this valve ensures efficient air flow control. Weighing just 7 oz, this valve offers a capacity CV of 1.54 (In to Out) and 1.84 (Out to Exhaust). Its plastic body construction, along with a 1/4 inch port size, provides durability and ease of installation. Trust in Rexroth quality for your industrial pneumatic needs.
Product Specifications
Specifications Capacity Cv In To Out
1.54
Specifications Capacity Cv Out To Exh
1.84
Specifications Intermittent Temperature Range
200 ºF
Specifications Maximum Working Pressure
150 psi
Specifications Media
Air
Specifications Old Part
P -069324-00002 | P 069324-2 | P 69324-2 | P069324-2 | P69324-2
Specifications Port Size
1/4 Inch
Specifications Temperature Range
-20 to 160 ºF
Specifications Type
In-Line
Specifications Weight
7 oz
