Right Angle Female Male Adapter - 6.5/15 kVDC Coaxial Connector Series
Right Angle Female Male Adapter - 6.5/15 kVDC Coaxial Connector Series
SKU:HIG-effca7
High voltage Right Angle Female Male Adapter with sea level rating and 10 Amp current capacity. Mates all Series 311 Cond. 1 connectors.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Right Angle Female Male Adapter - 6.5/15 kVDC Coaxial Connector Series
$39.99
Quantity: 1
Claim Your Seller Account
Right Angle Female Male Adapter - 6.5/15 kVDC Coaxial Connector Series
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Right Angle Female Male Adapter from the 6.5 and 15 kVDC Coaxial Connector Series is a durable and reliable solution for high voltage applications. Featuring a sea level rating and a current rating of 10 Amp, this non-standard part is designed to operate in temperatures ranging from -40 to 85 °C. With a test voltage of 7.5 kVDC for 15 seconds, this adapter is meticulously crafted with brass coupling nut material and gold-plated finish for optimal performance. It mates seamlessly with all Series 311 Cond. 1 receptacles and adaptors, providing a secure and efficient connection for your high voltage needs.
Product Specifications
Body Properties Coupling Nut Finish
Gold Plated
Body Properties Coupling Nut Material
Brass
Contact Properties Contact Material
Beryllium Copper
Specifications Altitudereduced Pressure Rating
Sea Level
Specifications Assembly Type
Right Angle Adapter
Specifications Coupling Style
Bayonet
Specifications Current Rating
10 Amp
Specifications Export Classification
TBD
Specifications Mating Compatibility
Mates all Series 311 Cond. 1 receptacles and adaptors.
Specifications Operating Temperature
-40 to 85 ºC
Specifications Polarization
Cond. 1
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
31
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
7.5 kVDC for 15 sec.
Specifications Voltage Rating
6.5 kVDC
