Rightway Hoists Model RPM 5 Ton Low Headroom Monorail Hoists
Rightway Hoists Model RPM 5 Ton Low Headroom Monorail Hoists
SKU:RIG-e782fc
Powerful and reliable 5-ton low headroom monorail hoists designed for industrial applications.
Regular price
$9,999.99
Regular price
Sale price
$9,999.99
Unit price
per
Initiate Order
Rightway Hoists Model RPM 5 Ton Low Headroom Monorail Hoists
$9,999.99
Quantity: 1
Claim Your Seller Account
Rightway Hoists Model RPM 5 Ton Low Headroom Monorail Hoists
$9,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Rightway Hoists Model RPM Low Headroom Monorail Hoists are engineered for exceptional performance in industrial applications. With a 5-ton capacity, 20' lift, and 22 inches headroom, these hoists are equipped with premium features like upper and lower limit switches, 250% torque hoist motor brake, and NEMA rated contactors. The hoists boast helical gearing for quiet operation, trolley drive on both sides of the beam, and a trolley brake for optimal safety. Meeting stringent industry standards, these hoists offer reliability, durability, and efficiency for a wide range of lifting needs.
Product Specifications
Specifications Cable Diameter
3/8 inches
Specifications Capacity
5 Tons
Specifications Head Room
22 inches
Specifications Hoists
7 1/2 HP
Specifications Hoist Speed
20
Specifications Lift
20'-0"
Specifications Options
2 Speed Hoist | 2 Speed Trolley | Special Lifts and Speeds | Overload Limit Switches
Specifications Reeving
4PS
Specifications Trolley Motor
3/4 HP
Specifications Trolley Speed
60
Specifications Weight
1175 lbs.
Standard Features 0
Upper and Lower Limit Switch 250% Torque Hoist Motor Brake NEMA Rated Contactors No Overhung Gears or Pinions Low Headroom Construction All Gears Operate In Oil Bath Helical Gearing For Quiet Operation Trolley Drive on Both Sides of Beam 100% Trolley Brake NEMA 1 Control Enclosure 115 Volt Fused Control Circuit 230/460-3-60 AC Dual Wound Motors TENV Class "F" Insulated Motors M.R.O.P. (Motor Running Overcurrent Protection) M.O.P. (Motor Overcurrent Protection) All Steel Drum with Machined Grooves Safety Drop Lugs on Trolley
