RMT H-FAB C-Frame 220 Ton Single Action Press
RMT H-FAB C-Frame 220 Ton Single Action Press
Enhance metalworking efficiency with the RMT H-FAB C-Frame 220 Ton Single Action Press. 220 US ton capacity, 24-inch daylight, 16-inch stroke, and essential safety features.
Regular price
$54,999.99
Regular price
Sale price
$54,999.99
Unit price
per
Initiate Order
RMT H-FAB C-Frame 220 Ton Single Action Press
$54,999.99
Quantity: 1
Claim Your Seller Account
RMT H-FAB C-Frame 220 Ton Single Action Press
$54,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience powerful and precise metalworking with the RMT H-FAB C-Frame 220 Ton Single Action Press. Designed with a robust 15 hp motor, this press offers a 220 US ton capacity with a 24-inch daylight and a 16-inch stroke. Features include a chrome plated cylinder, safety cover, adjustable pressure, and more. Optional HMI touchscreen panel available for enhanced control. Manufactured without sourcing components from China, ensuring reliability and quality standards.
Product Specifications
Dimensions Height
114 in
Dimensions Length
75 in
Dimensions Width
67 in
Note
We do not source any component of our presses from China.
Optional Features
HMI touchscreen panelDie sets
Specifications Capacity
220 US t
Specifications Daylight
24 in
Specifications Down Speed
21 in/min
Specifications Frame Design
C-Frame
Specifications Motor Power
15 hp
Specifications Open Height
8 in
Specifications Pump
9 gal
Specifications Return Speed
43 in/min
Specifications Slide Action
Single Action
Specifications Stroke
16 in
Specifications Weight
28,660 lb
Specifications Working Speed
24 in/min
Standard Features
Chrome plated cylinderSteel welded frameSafety cover and light barrierTwo hand button controlAdjustable pressure by regulatorAdjustable stroke by sensorOil pressure gaugeAir coolingT-slotted tableCommon off the shelf components, typically of German or USA origin (Rexroth, Parker, Schneiders, and Siemens)
Table Size Table Length
36 in
Table Size Table Width
24 in
