RMT H-FAB C-Frame 275 Ton Single Action Press
RMT H-FAB C-Frame 275 Ton Single Action Press
Enhance productivity and precision with the RMT H-FAB C-Frame 275 Ton Single Action Press, designed for reliability and accuracy in heavy-duty applications.
Regular price
$46,999.00
Regular price
Sale price
$46,999.00
Unit price
per
Initiate Order
RMT H-FAB C-Frame 275 Ton Single Action Press
$46,999.00
Quantity: 1
Claim Your Seller Account
RMT H-FAB C-Frame 275 Ton Single Action Press
$46,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The RMT H-FAB C-Frame 275 Ton Single Action Press combines precision engineering with robust construction, offering a reliable solution for heavy-duty pressing operations. With a 275 US ton capacity, 16-inch stroke, and 24-inch daylight, this press ensures efficiency and accuracy. Equipped with standard features like a chrome-plated cylinder, adjustable pressure control, and safety measures, it meets stringent industry standards. Optional HMI touchscreen panel and die sets enhance versatility for diverse applications. Proudly free from Chinese components, this press exemplifies quality and performance.
Product Specifications
Dimensions Height
114 in
Dimensions Length
79 in
Dimensions Width
63 in
Note
We do not source any component of our presses from China.
Optional Features
HMI touchscreen panelDie sets
Specifications Capacity
275 US t
Specifications Daylight
24 in
Specifications Down Speed
21 in/min
Specifications Frame Design
C-Frame
Specifications Motor Power
15 hp
Specifications Open Height
8 in
Specifications Pump
12 gal
Specifications Return Speed
43 in/min
Specifications Slide Action
Single Action
Specifications Stroke
16 in
Specifications Weight
30,865 lb
Specifications Working Speed
19 in/min
Standard Features
Chrome plated cylinderSteel welded frameSafety cover and light barrierTwo hand button controlAdjustable pressure by regulatorAdjustable stroke by sensorOil pressure gaugeAir coolingT-slotted tableCommon off the shelf components, typically of German or USA origin (Rexroth, Parker, Schneiders, and Siemens)
Table Size Table Length
40 in
Table Size Table Width
24 in
