RMT H-SMART 66 Ton C-Frame Single Action Press
RMT H-SMART 66 Ton C-Frame Single Action Press
Enhance production with the RMT H-SMART 66 Ton C-Frame Single Action Press. Precision, power, and safety in one machine.
Regular price
$23,999.00
Regular price
Sale price
$23,999.00
Unit price
per
Initiate Order
RMT H-SMART 66 Ton C-Frame Single Action Press
$23,999.00
Quantity: 1
Claim Your Seller Account
RMT H-SMART 66 Ton C-Frame Single Action Press
$23,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The RMT H-SMART 66 Ton C-Frame Single Action Press is a robust and versatile industrial machine designed for precision forming and stamping operations. With a capacity of 66 US tons and advanced servo hydraulic system, this press delivers exceptional performance and accuracy. Featuring a sturdy steel welded frame, HMI touchscreen control panel for seamless operation, and safety cover with light barrier, this press ensures operator safety and efficiency. Optional features like ejector cylinder, variable speeds, and heated platens enhance its functionality, making it ideal for diverse manufacturing applications. Notably, all components are sourced from reputable manufacturers like Rexroth and Siemens, ensuring top-notch quality and reliability.
Product Specifications
Dimensions Height
138 in
Dimensions Length
59 in
Dimensions Width
55 in
Note
We do not source any component of our presses from China.
Optional Features
Ejector cylinderVariable speedsDie setsCushionHeated platens
Specifications Capacity
66 US t
Specifications Daylight
20 in
Specifications Down Speed
236 in/min
Specifications Frame Design
C-Frame
Specifications Motor Power
10 hp
Specifications Open Height
4 in
Specifications Optional Cushion Stroke
6 in
Specifications Pump
6 gal
Specifications Return Speed
354 in/min
Specifications Slide Action
Single Action
Specifications Stroke
16 in
Specifications Weight
7,716 lb
Specifications Working Speed
24 in/min
Standard Features
Chrome plated cylinderSteel welded frameServo hydraulic systemHMI touchscreen control panelSafety cover and light barrierTwo hand button controlAdjustable variable pressure on HMI touchscreen control panelAdjustable stroke on HMI touchscreen control panelAdjustable variable speed on HMI touchscreen control panelOil pressure gaugeAir coolingT-slotted table and ramCommon off the shelf components, typically of German or USA origin (Rexroth, Parker, Schneiders, and Siemens)
Table Size Table Length
20 in
Table Size Table Width
20 in
