RMT H-SMART C-Frame 110 Ton Single Action Press
RMT H-SMART C-Frame 110 Ton Single Action Press
Enhance manufacturing capabilities with the RMT H-SMART C-Frame 110 Ton Press - precision and power combined.
Regular price
$74,999.99
Regular price
Sale price
$74,999.99
Unit price
per
Initiate Order
RMT H-SMART C-Frame 110 Ton Single Action Press
$74,999.99
Quantity: 1
Claim Your Seller Account
RMT H-SMART C-Frame 110 Ton Single Action Press
$74,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience precision and power with the RMT H-SMART C-Frame 110 Ton Single Action Press. Engineered with a robust frame design, this press ensures consistent performance with a 110 US ton capacity. Featuring a servo hydraulic system, adjustable stroke and speed controls, and safety enhancements like a touchscreen control panel and light barriers, this press offers versatility and efficiency. With optional features like ejector cylinders and variable speeds, this press caters to diverse industrial needs. Proudly sourced from brands like Rexroth, Parker, and Siemens, this press prioritizes quality and reliability.
Product Specifications
Dimensions Height
115 in
Dimensions Length
63 in
Dimensions Width
67 in
Note
We do not source any component of our presses from China.
Optional Features
Ejector cylinderVariable speedsDie setsCushionHeated platens
Specifications Capacity
110 US t
Specifications Daylight
20 in
Specifications Down Speed
236 in/min
Specifications Frame Design
C-Frame
Specifications Motor Power
15 hp
Specifications Open Height
4 in
Specifications Optional Cushion Stroke
6 in
Specifications Pump
7 gal
Specifications Return Speed
378 in/min
Specifications Slide Action
Single Action
Specifications Stroke
16 in
Specifications Weight
12,125 lb
Specifications Working Speed
24 in/min
Standard Features
Chrome plated cylinderSteel welded frameServo hydraulic systemHMI touchscreen control panelSafety cover and light barrierTwo hand button controlAdjustable variable pressure on HMI touchscreen control panelAdjustable stroke on HMI touchscreen control panelAdjustable variable speed on HMI touchscreen control panelOil pressure gaugeAir coolingT-slotted table and ramCommon off the shelf components, typically of German or USA origin (Rexroth, Parker, Schneiders, and Siemens)
Table Size Table Length
32 in
Table Size Table Width
20 in
