RMT H-SMART C-Frame 165T Single Action Press
RMT H-SMART C-Frame 165T Single Action Press
Experience precision and power with the RMT H-SMART C-Frame 165T Single Action Press. Customize for your needs!
Regular price
$58,999.99
Regular price
Sale price
$58,999.99
Unit price
per
Initiate Order
RMT H-SMART C-Frame 165T Single Action Press
$58,999.99
Quantity: 1
Claim Your Seller Account
RMT H-SMART C-Frame 165T Single Action Press
$58,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The RMT H-SMART C-Frame 165T Single Action Press is a powerhouse in precision engineering. With a 165 US ton capacity, this press ensures efficient operations with its dependable features like chrome plated cylinder, servo hydraulic system, and adjustable stroke and speed controls. Its sturdy construction, German or USA-origin components, and advanced safety mechanisms guarantee optimal performance. Ideal for industrial applications, this press can be customized to meet specific requirements.
Product Specifications
Dimensions Height
134 in
Dimensions Length
83 in
Dimensions Width
71 in
Note
We do not source any component of our presses from China.
Optional Features
Ejector cylinderVariable speedsDie setsCushionHeated platens
Specifications Capacity
165 US t
Specifications Daylight
20 in
Specifications Down Speed
260 in/min
Specifications Frame Design
C-Frame
Specifications Motor Power
15 hp
Specifications Open Height
4 in
Specifications Optional Cushion Stroke
6 in
Specifications Pump
11 gal
Specifications Return Speed
354 in/min
Specifications Slide Action
Single Action
Specifications Stroke
16 in
Specifications Weight
26,456 lb
Specifications Working Speed
20 in/min
Standard Features
Chrome plated cylinderSteel welded frameServo hydraulic systemHMI touchscreen control panelSafety cover and light barrierTwo hand button controlAdjustable variable pressure on HMI touchscreen control panelAdjustable stroke on HMI touchscreen control panelAdjustable variable speed on HMI touchscreen control panelOil pressure gaugeAir coolingT-slotted table and ramCommon off the shelf components, typically of German or USA origin (Rexroth, Parker, Schneiders, and Siemens)
Table Size Table Length
32 in
Table Size Table Width
24 in
