The RMT H-SMART C-Frame 220T Single Action Press offers precision and power for industrial applications. Featuring a robust design with a 220 US ton capacity, this press ensures efficient operations with a 20 hp motor. Equipped with advanced features such as servo hydraulic system, HMI touchscreen control panel, and safety mechanisms, it prioritizes user safety and operational control. With optional add-ons like ejector cylinder and variable speeds, this press caters to diverse production needs, meeting the stringent requirements of both consumer and institutional buyers.
Product Specifications
Dimensions Height
134 in
Dimensions Length
83 in
Dimensions Width
71 in
Note
We do not source any component of our presses from China.
Optional Features
Ejector cylinderVariable speedsDie setsCushionHeated platens
Specifications Capacity
220 US t
Specifications Daylight
20 in
Specifications Down Speed
295 in/min
Specifications Frame Design
C-Frame
Specifications Motor Power
20 hp
Specifications Open Height
4 in
Specifications Optional Cushion Stroke
6 in
Specifications Pump
17 gal
Specifications Return Speed
426 in/min
Specifications Slide Action
Single Action
Specifications Stroke
16 in
Specifications Weight
28,660 lb
Specifications Working Speed
24 in/min
Standard Features
Chrome plated cylinderSteel welded frameServo hydraulic systemHMI touchscreen control panelSafety cover and light barrierTwo hand button controlAdjustable variable pressure on HMI touchscreen control panelAdjustable stroke on HMI touchscreen control panelAdjustable variable speed on HMI touchscreen control panelOil pressure gaugeAir coolingT-slotted table and ramCommon off the shelf components, typically of German or USA origin (Rexroth, Parker, Schneiders, and Siemens)
Table Size Table Length
36 in
Table Size Table Width
24 in
