Rotary Switch Boot - 1/4-32 UNEF-2B Thread, 0.23in Boot Height
Rotary Switch Boot - 1/4-32 UNEF-2B Thread, 0.23in Boot Height
SKU:SWI-1d2499
Protect standard switches in any environment with this durable, silicone Rotary Switch Boot.
Regular price
$19.99
Regular price
Sale price
$19.99
Unit price
per
Initiate Order
Rotary Switch Boot - 1/4-32 UNEF-2B Thread, 0.23in Boot Height
$19.99
Quantity: 1
Claim Your Seller Account
Rotary Switch Boot - 1/4-32 UNEF-2B Thread, 0.23in Boot Height
$19.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Rotary Switch Boot features a single-piece design that effortlessly fits over standard switches, providing superior protection in harsh environments. Crafted from silicone with a durometer of 60, it offers resistance to fungus, oils, weather elements, and more. With an IP68 enclosure protection rating and a temperature range of -93 to +400°F, this boot is ideal for aerospace, industrial, marine, medical, and military applications. Safeguard your equipment from water, oil, sand, and other contaminants with this durable and reliable switch boot.
Product Specifications
Specifications Applications
Aerospace | For Indoor/Outdoor Use to protect against exposure to harsh environments | Industrial Equipment | Marine | Medical Equipment | Military
Specifications Base Width Hex
0.375 in
Specifications Boot Height
0.23 in
Specifications Bushing Thread Size Unified
1/4-32 UNEF-2B
Specifications Color
Black | Gray
Specifications Durometer
60
Specifications Enclosure Protection
IP68 (Under Normal Conditions)
Specifications External Pressure Range
15 psi
Specifications Internal Pressure Range
15 psi
Specifications Material
Silicone
Specifications Mounting Nut
Corrosion Resistant - Nickel Plated Brass
Specifications Note
Designed to protect from water, oil, sand, dust, dirt, humidity, precipitation and other contaminants.
Specifications Resistant To
Fungus | Most Acids and Lubricating Oils | Ozone | Salt Spray | Sunlight | Weather
Specifications Temperature Range
-93 to +400 ºF
Specifications Thread Type
Unified National Coarse Thread (UNC)
