RTV-846 Room Temperature Vulcanizing Silicone Rubber
RTV-846 Room Temperature Vulcanizing Silicone Rubber
SKU:RTV-e0b09b
High-performance RTV-846 Silicone Rubber for aerospace and electronics potting applications
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
RTV-846 Room Temperature Vulcanizing Silicone Rubber
$29.99
Quantity: 1
Claim Your Seller Account
RTV-846 Room Temperature Vulcanizing Silicone Rubber
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The RTV-846 Room Temperature Vulcanizing (RTV) Silicone Rubber is a high-performance condensation cure syntactic foam silicone with outstanding flow properties and low density. Designed for potting electronics requiring low dielectric constant and low capacitance, RTV-846 is ideal for aerospace and aircraft applications. With a comprehensive set of specifications including color, viscosity, tensile strength, and tear strength, this silicone rubber ensures reliability and durability in various environments. Its service temperature range of -54 to 204°C, along with excellent electrical properties like dielectric strength and volume resistivity, makes it a top choice for institutional and government procurement needs.
Product Specifications
Specifications Coefficient Of Thermal Expansion
2.2 x 104 cm/cm-ºC
Specifications Color
White
Specifications Cure Schedule
24 hours (h) at room temperaturePot Life and cure is dependent on temperature and humidity.Ideal conditions: 68 to 78ºF (20 to 26ºC)40 to 60% relative humidity
Specifications Dielectric Constant At 100 Hertz Hz
2.5
Specifications Dielectric Strength
500 V/mil
Specifications Dissipation Factor At 60 Hertz Hz
0.002
Specifications Instructions For Use
Pre-mix RTV-846 Base thoroughly. Weigh out the required amount and add the required amount of Catalyst. Mix thoroughly scraping both the bottom and sides of the mixing container. Apply material.
Specifications Linear Shrinkage
0.06 %
Specifications Mixed Viscosity
10000 cps
Specifications Mix Ratio By Weight
100:10
Specifications Pot Life At 72 F
120 min
Specifications Service Temperature Range
-54 to 204 ºC
Specifications Shelf Life At 72 F
12 m
Specifications Shore A Hardness
45 duro
Specifications Specific Gravity
0.70
Specifications Tear Strength
20 ppi
Specifications Tensile Elongation
100 %
Specifications Tensile Strength
350 psi
Specifications Thermal Conductivity
1 Btu/in/ft²hr/ºF
Specifications Viscosity
25000 cps
Specifications Volume Resistivity
1 x 1015 ohm-cm
