Enhance your system's performance with the Greenray Industries Y1600 XO VCXO Quartz Crystal Oscillator. This compact and rugged oscillator offers exceptional phase noise performance for frequencies ranging from 10 to 100 MHz. With a robust design built for reliability and precision, this oscillator ensures stability across varying temperatures and environmental conditions. Ideal for telecommunications, high-shock electronics, and airborne communications, it meets MIL Screening to MIL-PRF-55310 standards, making it suitable for demanding applications requiring strict compliance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
TelecommunicationsHigh-shock electronicsMobile radioMobile instrumentationAirborne communicationsWireless communicationsMicrowave receivers
Electrical Characteristics Maximum Acceleration Sensitivity
2.5 ppb/g
Electrical Characteristics Maximum Aging At 10 Years 10 Megahert
3 ppm
Electrical Characteristics Maximum Aging Tolerance For 1 Year
1.0 ppm
Electrical Characteristics Maximum Direct Current Dc Supply Volt
5.25 V
Electrical Characteristics Maximum Frequency Versus Load For A 1
0.1 ppm
Electrical Characteristics Maximum Frequency Versus Voltage For
0.1 ppm
Electrical Characteristics Maximum Level 0 15 Power Factor Pf Lo
+0.2 V
Electrical Characteristics Maximum Nominal Frequency At High Spe
100 MHz
Electrical Characteristics Maximum Supply Current At 10 Megahert
15 mA
Electrical Characteristics Maximum Symmetry At Complementary Met
55 %
Electrical Characteristics Minimum Direct Current Dc Supply Volt
4.75 V
Electrical Characteristics Minimum Level 1 15 Power Factor Pf Lo
+4.5 V
Electrical Characteristics Minimum Load At Complementary Metal O
10 pF
Electrical Characteristics Minimum Nominal Frequency At High Spe
10 MHz
Electrical Characteristics Minimum Symmetry At Complementary Met
45 %
Electrical Characteristics Note For Acceleration Sensitivity
Acceleration Sensitivity is worst axis tested at 90 Hz, 10 g
Electrical Characteristics Note For Frequency Stability
Other Stability Available
Electrical Characteristics Direct Current Dc Supply Volt
5.0 V
Electrical Characteristics Electronic Frequency Control
10 ppm
Electrical Characteristics Frequency Stability At 0 To 5
5 ppm
Electrical Characteristics Frequency Stability At 20 To
10 ppm
Electrical Characteristics Frequency Stability At 40 To
15 ppm
Electrical Characteristics Load At Complementary Metal O
15 pF
Electrical Characteristics Symmetry At Complementary Met
50 %
Environmental And Mechanical Specifications Random Vibration
StandardMIL-STD-202Method, Condition214, Cond I-ADescription0.2 PSD, 5.35 rms G
Environmental And Mechanical Specifications Shock
StandardMIL-STD-202Method, Condition213, Cond CDescription100 g, 6 ms half-sine
Environmental And Mechanical Specifications Sine Vibration
StandardMIL-STD-202Method, Condition204, Cond DDescription20 g, 20 to 2,000 Hz
Features Features
HCMOS outputMIL Screening to MIL-PRF-55310 availableRandom Vibration per MIL-STD-202, Method 214Shock perMIL-STD-202, Method 213RoHS compliant
Phase Noise Performance Phase Noise At 10 Megahertz Mhz
-162 dBc/Hz
Recommendation And General Information Marking
Line 1: Greenray logo + ModelLine 2: FrequencyLine 3: Serial Number + Data Code (YYWW)
Recommendation And General Information Operating Temperature
-40 to +85 ºC
Recommendation And General Information Package Weight
3 g
Recommendation And General Information Shipping
Tray
Specifications Direct Current Dc Supply Voltage
5 V
Specifications Package Size
17.3 mm²
