S05 Metallic Ball Valve Diaphragm Pump - Air Operated Double Diaphragm Pump

Name: S05 Metallic Ball Valve Diaphragm Pump - Air Operated Double Diaphragm Pump
Brand: Springer Pumps, LLC
SKU: PRO-03198d
Price: 699.99 USD
Availability: OutOfStock

SKU:PRO-03198d

High-performance S05 Metallic Ball Valve Diaphragm Pump for precise liquid transfer, durable construction, and chemical compatibility.

$699.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The S05 Metallic Ball Valve Diaphragm Pump is a reliable and efficient solution for various liquid transfer applications. With a robust design and Hastelloy construction, it ensures durability and corrosion resistance. Featuring a UniRupp® PTFE/PTFE diaphragm with PTFE check valve seat, it offers superior performance and chemical compatibility. This pump is ideal for standard duty pumping requirements, with a 0-15 gpm flow rate and 0.026 gal displacement per stroke. Ball check valve type ensures precise control and smooth operation. Invest in this pump for high-quality results in water, wastewater, sump, and utility applications.

Product Specifications

Specifications Check Valve Seat

PTFE

Specifications Check Valve Type

Ball

Specifications Design Level

Specifications Discharge Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Displacement Per Stroke

0.026 gal | 0.098 lit

Specifications Elastomers

UniRuppÂ® PTFE/PTFE

Specifications Intake Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Max Flow Rate

0 - 15 gpm | 0 - 56 lpm

Specifications Non Wetted Material

Aluminum

Specifications Porting Position

NPT Threads

Specifications Pump Style

Standard

Specifications Solids Handling

0.125 in | 3 mm

Specifications Type

Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty

Specifications Weight

23 lbs | 11 kg

Specifications Wetted Moc

Hastelloy
