S05 Metallic Ball Valve Diaphragm Pump - Air Operated Double Diaphragm Pump

Name: S05 Metallic Ball Valve Diaphragm Pump - Air Operated Double Diaphragm Pump
Brand: Springer Pumps, LLC
SKU: PRO-26c372
Price: 489.99 USD
Availability: OutOfStock

SKU:PRO-26c372

Powerful S05 Metallic Ball Valve Diaphragm Pump - Ideal for standard duty applications

$489.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The S05 Metallic Ball Valve Diaphragm Pump is a powerful air-operated double diaphragm pump designed for standard duty applications. With a Hastelloy wetted material of construction and Viton/PTFE elastomers, this pump ensures optimal performance and chemical compatibility. Its ball check valve type, PTFE check valve seat, and aluminum non-wetted material guarantee durability and efficiency. Ideal for handling waste water with solids up to 0.125 inches, this pump offers a maximum flow rate of 15 gpm. Trusted by industries for its reliability and sandpiper standard duty design, this pump is a versatile solution for water, wastewater, sump, and utility pumping needs.

Product Specifications

Specifications Check Valve Seat

PTFE

Specifications Check Valve Type

Ball

Specifications Design Level

Specifications Discharge Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Displacement Per Stroke

0.026 gal | 0.098 lit

Specifications Elastomers

VitonÂ®/PTFE

Specifications Intake Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Max Flow Rate

0 - 15 gpm | 0 - 56 lpm

Specifications Non Wetted Material

Aluminum

Specifications Porting Position

NPT Threads

Specifications Pump Style

Standard

Specifications Solids Handling

0.125 in | 3 mm

Specifications Type

Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty

Specifications Weight

23 lbs | 11 kg

Specifications Wetted Moc

Hastelloy

Category 6

Standard Duty Diaphragm Pumps

S05 Metallic Ball Valve Diaphragm Pump - Air Operated Double Diaphragm Pump
