S05 Metallic Ball Valve Diaphragm Pump - Air Operated, Standard Duty

Name: S05 Metallic Ball Valve Diaphragm Pump - Air Operated, Standard Duty
Brand: Springer Pumps, LLC
SKU: PRO-4a9fcc
Price: 899.99 USD
Availability: OutOfStock

SKU:PRO-4a9fcc

High-performance S05 Metallic Ball Valve Diaphragm Pump for water and wastewater applications. Air-operated with a max flow rate of 15 gpm.

$899.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The S05 Metallic Ball Valve Diaphragm Pump is a top-of-the-line choice for water and wastewater applications requiring reliability and efficiency. With a check valve type of ball and wetted M.O.C. of Hastelloy, this pump offers exceptional durability and corrosion resistance. Its air-powered double diaphragm design, along with a maximum flow rate of 15 gpm, ensures optimal performance. Ideal for institutional and government buyers seeking top ported AOD pumps that meet strict standards.

Product Specifications

Specifications Check Valve Seat

UHMW Polyethylene

Specifications Check Valve Type

Ball

Specifications Design Level

Specifications Discharge Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Displacement Per Stroke

0.026 gal | 0.098 lit

Specifications Elastomers

SantopreneÂ®/SantopreneÂ®

Specifications Intake Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Max Flow Rate

0 - 15 gpm | 0 - 56 lpm

Specifications Non Wetted Material

Aluminum

Specifications Porting Position

NPT Threads

Specifications Pump Style

Standard

Specifications Solids Handling

0.125 in | 3 mm

Specifications Type

Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty

Specifications Weight

23 lbs | 11 kg

Specifications Wetted Moc

Hastelloy

Category 6

Standard Duty Diaphragm Pumps

S05 Metallic Ball Valve Diaphragm Pump - Air Operated, Standard Duty
