S05 Metallic Ball Valve Diaphragm Pump - Air Powered AODP

Name: S05 Metallic Ball Valve Diaphragm Pump - Air Powered AODP
Brand: Springer Pumps, LLC
SKU: PRO-243fc7
Price: 749.99 USD
Availability: OutOfStock

SKU:PRO-243fc7

Efficient S05 Metallic Ball Valve Diaphragm Pump for waste water management, with durable construction and high flow rate.

$749.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The S05 Metallic Ball Valve Diaphragm Pump is a high-performance air-powered double diaphragm pump designed for standard duty applications in waste water management. Featuring a Hastelloy wetted M.O.C. and Neoprene elastomers, this pump ensures durability and chemical resistance. With a max flow rate of 15 gpm, 0.026 gal displacement per stroke, and 0.125" solids handling capacity, it delivers efficient pumping in industrial settings. The ball check valve type and UHMW Polyethylene check valve seat enhance performance and reliability, making it ideal for water, wastewater, sump, and utility applications.

Product Specifications

Specifications Check Valve Seat

UHMW Polyethylene

Specifications Check Valve Type

Ball

Specifications Design Level

Specifications Discharge Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Displacement Per Stroke

0.026 gal | 0.098 lit

Specifications Elastomers

Neoprene/Neoprene

Specifications Intake Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Max Flow Rate

0 - 15 gpm | 0 - 56 lpm

Specifications Non Wetted Material

Aluminum

Specifications Porting Position

NPT Threads

Specifications Pump Style

Standard

Specifications Solids Handling

0.125 in | 3 mm

Specifications Type

Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty

Specifications Weight

23 lbs | 11 kg

Specifications Wetted Moc

Hastelloy

Category 6

Standard Duty Diaphragm Pumps

S05 Metallic Ball Valve Diaphragm Pump - Air Powered AODP
