S05 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
S05 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
SKU:PRO-7ded41
Durable S05 Metallic Ball Valve Diaphragm Pump for industrial wastewater applications. Hastelloy construction, 0.125in solids handling, 15 gpm flow rate.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
S05 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
$899.99
Quantity: 1
Claim Your Seller Account
S05 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The S05 Metallic Ball Valve Diaphragm Pump is a robust and reliable air-powered double diaphragm pump designed for standard duty applications in wastewater management. With a Hastelloy construction, this pump offers exceptional corrosion resistance and durability. Its ball check valve type ensures efficient operation with solids handling capability up to 0.125 inches. The pump's design meets Sandpiper standard duty requirements and is suited for industrial settings requiring a maximum flow rate of 15 gpm.
Product Specifications
Specifications Check Valve Seat
UHMW Polyethylene
Specifications Check Valve Type
Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
1/2" BSPT | 1/2" NPT
Specifications Displacement Per Stroke
0.026 gal | 0.098 lit
Specifications Elastomers
EPDM/EPDM
Specifications Intake Pipe Size Internal
1/2" BSPT | 1/2" NPT
Specifications Max Flow Rate
0 - 15 gpm | 0 - 56 lpm
Specifications Non Wetted Material
Aluminum
Specifications Porting Position
NPT Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.125 in | 3 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Weight
23 lbs | 11 kg
Specifications Wetted Moc
Hastelloy
Category 6
Standard Duty Diaphragm Pumps
