S05 Metallic Ball Valve Diaphragm Pump - Industrial Standard Duty

Name: S05 Metallic Ball Valve Diaphragm Pump - Industrial Standard Duty
Brand: Springer Pumps, LLC
SKU: PRO-8e0274
Price: 549.99 USD
Availability: OutOfStock

SKU:PRO-8e0274

Top-tier air-operated double diaphragm pump for industrial use. Stainless steel construction with 15 gpm flow rate.

$549.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The S05 Metallic Ball Valve Diaphragm Pump is a top-performing air-operated double diaphragm pump designed for industrial applications. With intake and discharge pipe sizes of 1/2'', it features a ball check valve, stainless steel wetted parts, and EPDM/EPDM elastomers for durability. This pump has a maximum flow rate of 15 gpm, making it ideal for standard duty waste water pumping. Compliant with industry standards, this pump ensures reliable performance in demanding environments.

Product Specifications

Specifications Check Valve Seat

UHMW Polyethylene

Specifications Check Valve Type

Ball

Specifications Design Level

Specifications Discharge Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Displacement Per Stroke

0.026 gal | 0.098 lit

Specifications Elastomers

EPDM/EPDM

Specifications Intake Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Max Flow Rate

0 - 15 gpm | 0 - 56 lpm

Specifications Non Wetted Material

Aluminum

Specifications Porting Position

NPT Threads

Specifications Pump Style

Standard

Specifications Solids Handling

0.125 in | 3 mm

Specifications Type

Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty

Specifications Weight

21 lbs | 10 kg

Specifications Wetted Moc

Stainless Steel
