S15 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
S15 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
SKU:PRO-8b9035
Versatile S15 Metallic Ball Valve Diaphragm Pump for water/waste water applications. Durable and efficient design for industrial use.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
S15 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
$899.99
Quantity: 1
Claim Your Seller Account
S15 Metallic Ball Valve Diaphragm Pump - Air Powered Double Diaphragm Pump
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The S15 Metallic Ball Valve Diaphragm Pump is a versatile solution for water and wastewater applications, featuring a sturdy construction with wetted materials of aluminum, cast iron, and stainless steel ensuring durability. With a displacement of 0.41 gallons per stroke and a maximum flow rate of 106 gpm, this pump is ideal for standard-duty pumping tasks. The pump's design level 1 and ball check valve type further enhance its efficiency and reliability, making it suitable for industrial and institutional use.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Check Valve Seat
Aluminum | Carbon Steel | Stainless Steel
Specifications Check Valve Type
Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
1 1/2" BSPT Tapered | 1 1/2" NPT
Specifications Displacement Per Stroke
0.41 gal | 1.55 lit
Specifications Elastomers
Buna/Buna | EPDM/EPDM | Neoprene/Neoprene | PTFE - Neoprene/PTFE | Santoprene/Santoprene | Viton®/PTFE | Viton®/Viton®
Specifications Intake Pipe Size Internal
1 1/2" BSPT Tapered | 1 1/2" NPT
Specifications Max Flow Rate
0 - 106 gpm | 0 - 401 lpm
Specifications Non Wetted Material
Cast Iron | Cast Iron with Stainless Steel Hardware | Painted Aluminum with PTFE Coated Hardware | Painted Aluminum with Stainless Steel Hardware
Specifications Porting Position
BSPT (Tapered) Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.25 in | 6 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Wetted Moc
Aluminum | Cast Iron | Stainless Steel
Category 6
Standard Duty Diaphragm Pumps
