S20 Evolution Metallic Ball Valve Diaphragm Pump - Standard Duty, Air Powered
S20 Evolution Metallic Ball Valve Diaphragm Pump - Standard Duty, Air Powered
SKU:PRO-8b9035
Reliable S20 Evolution Diaphragm Pump for standard duty applications, ensures durability and efficient fluid handling.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
S20 Evolution Metallic Ball Valve Diaphragm Pump - Standard Duty, Air Powered
$799.99
Quantity: 1
Claim Your Seller Account
S20 Evolution Metallic Ball Valve Diaphragm Pump - Standard Duty, Air Powered
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The S20 Evolution Metallic Ball Valve Diaphragm Pump is a top-performing air-operated double diaphragm pump designed for standard duty applications. With a robust construction featuring aluminum, cast iron, and stainless steel wetted materials, it ensures durability and resistance to harsh environments. Equipped with EPDM/Santoprene and Viton/PTFE elastomers, it guarantees reliable performance and chemical compatibility. The weighted ball check valve, along with the aluminum, carbon steel, and stainless steel components, ensures efficient fluid handling and longevity. Delivering a displacement of 0.42 gallons per stroke and handling solids up to 0.25 inches, this pump is ideal for waste water applications. Trust the S20 Evolution for dependable pumping in demanding industrial settings.
Product Specifications
Specifications Check Valve Seat
Aluminum | Carbon Steel | Stainless Steel | Viton®
Specifications Check Valve Type
Weighted Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
2" BSPT Tapered | 2" NPT
Specifications Displacement Per Stroke
0.42 gal | 1.59 lit
Specifications Elastomers
EPDM/Santoprene | Viton®/PTFE
Specifications Intake Pipe Size Internal
2" BSPT Tapered | 2" NPT
Specifications Max Flow Rate
0 - 150 gpm | 0 - 567 lpm
Specifications Non Wetted Material
Cast Iron | Cast Iron with Stainless Steel Hardware | Painted Aluminum with PTFE Coated Hardware | Painted Aluminum with Stainless Steel Hardware
Specifications Porting Position
BSPT (Tapered) Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.25 in | 6 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Wetted Moc
Aluminum | Cast Iron | Stainless Steel
Category 6
Standard Duty Diaphragm Pumps
