S20 Non-Metallic Ball Valve Diaphragm Pump - Air Powered, Standard Duty

S20 Non-Metallic Ball Valve Diaphragm Pump - Air Powered, Standard Duty

PRO-a490ff

Reliable S20 Non-Metallic Diaphragm Pump for water/wastewater applications, with durable PVDF construction & 150 gpm flow rate.

$1,799.99
$1,799.99
Sale

Initiate Order

S20 Non-Metallic Ball Valve Diaphragm Pump - Air Powered, Standard Duty

S20 Non-Metallic Ball Valve Diaphragm Pump - Air Powered, Standard Duty

$1,799.99

Quantity: 1

Claim Your Seller Account

S20 Non-Metallic Ball Valve Diaphragm Pump - Air Powered, Standard Duty

S20 Non-Metallic Ball Valve Diaphragm Pump - Air Powered, Standard Duty

$1,799.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The S20 Non-Metallic Ball Valve Diaphragm Pump is a reliable air-powered double diaphragm pump designed for water, wastewater, sump, and utility applications. With a solids handling capacity of 0.66 inches and a max flow rate of 150 gpm, this pump delivers efficient performance. Constructed with PVDF wetted materials and Santoprene elastomers, it ensures durability and corrosion resistance. The pump meets industry-standard compliance and is suitable for government and institutional procurement needs.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Specifications Check Valve Seat
PVDF
Specifications Check Valve Type
Ball
Specifications Design Level
2
Specifications Displacement Per Stroke
0.36 gal | 1.36 lit
Specifications Elastomers
Santoprene/Santoprene
Specifications Inlet Size
2" ANSI Flange | PN10 50 mm DIN Flange
Specifications Max Flow Rate
0 - 150 gpm | 0 - 568 lpm
Specifications Non Wetted Material
Epoxy Coated Aluminum
Specifications Outlet Size
2" ANSI Flange | PN10 50 mm DIN Flange
Specifications Porting Position
ANSI Flange
Specifications Pump Style
Standard
Specifications Solids Handling
0.66 in | 17 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD Non-Metallic | Pumps - Sandpiper Standard Duty | Pumps - Sealless
Specifications Weight
117 lbs | 53 kg
Specifications Wetted Moc
PVDF
