S30 Evolution Metallic Ball Valve Diaphragm Pump
S30 Evolution Metallic Ball Valve Diaphragm Pump
SKU:PRO-8b9035
High-performance S30 Evolution Metallic Ball Valve Diaphragm Pump for efficient waste water handling. Max flow rate: 235 gpm. Ball check valve design. Suitable for solids up to 0.25 in.
Regular price
$1,699.99
Regular price
Sale price
$1,699.99
Unit price
per
Initiate Order
S30 Evolution Metallic Ball Valve Diaphragm Pump
$1,699.99
Quantity: 1
Claim Your Seller Account
S30 Evolution Metallic Ball Valve Diaphragm Pump
$1,699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The S30 Evolution Metallic Ball Valve Diaphragm Pump is a top-performing air-powered double diaphragm pump designed for standard duty applications in waste water handling. With a max flow rate of 235 gpm, this pump features a robust construction using Alloy C, Aluminum, Cast Iron, and Stainless Steel materials. Its ball check valve design ensures reliable operation and the intake/discharge pipe sizes (3") allow efficient pumping. Equipped with EPDM/Santoprene and Viton/PTFE elastomers, this pump delivers a displacement of 0.94 gal per stroke, making it a dependable choice for handling solids up to 0.25 inches.
Product Specifications
Specifications Check Valve Seat
Aluminum | Carbon Steel | Stainless Steel | Viton®
Specifications Check Valve Type
Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
3" BSPT Tapered | 3" NPT
Specifications Displacement Per Stroke
0.94 gal | 3.56 lit
Specifications Elastomers
EPDM/Santoprene | Viton®/PTFE
Specifications Intake Pipe Size Internal
3" BSPT Tapered | 3" NPT
Specifications Max Flow Rate
0 - 235 gpm | 0 - 889 lpm
Specifications Non Wetted Material
Cast Iron | Cast Iron with Stainless Steel Hardware | Painted Aluminum with PTFE Coated Hardware | Painted Aluminum with Stainless Steel Hardware
Specifications Porting Position
BSPT (Tapered) Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.25 in | 6 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Wetted Moc
Alloy C | Aluminum | Cast Iron | Stainless Steel
Category 6
Standard Duty Diaphragm Pumps
