Safelec 2 Copper Conductor Bars with Splice Installed, 160A, 50mm²

Safelec 2 Copper Conductor Bars with Splice Installed, 160A, 50mm²

CRA-beae1d

Upgrade crane control with Safelec 2 Copper Conductor Bars for reliable 160A performance & UV resilient PVC cover.

$289.99
$289.99
Sale

Initiate Order

Safelec 2 Copper Conductor Bars with Splice Installed, 160A, 50mm²

Safelec 2 Copper Conductor Bars with Splice Installed, 160A, 50mm²

$289.99

Quantity: 1

Claim Your Seller Account

Safelec 2 Copper Conductor Bars with Splice Installed, 160A, 50mm²

Safelec 2 Copper Conductor Bars with Splice Installed, 160A, 50mm²

$289.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
Enhance efficiency in crane control with our Safelec 2 Copper Conductor Bars with Splice Installed. With an impressive amperage rating of 160A and UV stable PVC cover, these bars ensure reliable performance within a 600V system. The copper construction, along with low resistance and impedance, guarantees optimal conductivity. Meeting stringent industry standards, these bars come in a 4.5m length, making them ideal for various settings requiring safe and durable electrification solutions.

Product Specifications

Cover Specifications Cover Material
PVC
Cover Specifications Dielectric Strength
180 kv/cm
Cover Specifications Flame Test
Self Extinguishing
Cover Specifications Oxygen Index
54%
Cover Specifications Specific Density
1.5 g/cm³
Cover Specifications Surface Resistivity
1011 Ω
Cover Specifications Vicat Softening Temperature
160 ºF | 71.1 ºC
Cover Specifications Volume Resistivity
>1015 Ω/cm
Specifications Amperage Rating
160 A
Specifications Bar Length
4.5 m
Specifications Cover Type
UV Stable (Black)
Specifications Cross Sectional Area
50 mm²
Specifications Expansion Sections
150 m
Specifications Impedance Z For Ac At 20 C
0.000364 Ω/m
Specifications Material
Copper
Specifications Maximum Allowable Ambient Temperature
25 ºC
Specifications Maximum System Voltage Ac Or Dc Per Ul Listing
600 V
Specifications Minimum Bending Radius
1.5 m
Specifications Minimum Pitch Centers Standard
43 mm
Specifications Nominal Current
160 A
Specifications Resistance R For Dc At 20 C
0.000342 Ω/m
Specifications Support Pitch Lateral
1125 mm
Specifications Support Pitch Standard
1500 mm
Specifications Weight
6.2 lb | 2.8 kg
