San Ace 120 Series AC Fan - Model 109S013UL
San Ace 120 Series AC Fan - Model 109S013UL
SKU:SAN-0008c7
High-performance San Ace 120 Series AC Fan - Model 109S013UL with aluminum frame and UL94V-1 rated plastics, ideal for efficient heat dissipation in demanding environments.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 120 Series AC Fan - Model 109S013UL
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 120 Series AC Fan - Model 109S013UL
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 120 Series AC Fan, Model 109S013UL, is a high-quality cooling solution designed for reliable performance in demanding environments. With dimensions of 120x120x38 mm and a sturdy aluminum frame, this fan ensures efficient heat dissipation. The impeller is made of UL94V-1 rated plastics, providing enhanced safety. Operating at a voltage of 100V with a frequency of 50/60 Hz, this fan delivers a maximum air flow of 1.75 m³/min and a maximum static pressure of 26.4 Pa. It boasts a sound pressure level of 32 dBA and has an expected life of 25,000 hours at 60°C, making it a durable and efficient choice for cooling systems.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Current
0.16/0.14 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between input terminal and frame)
Specifications Dielectric Strength With Sensor Between Ac Input
50/60 Hz 1,500 VAC 1 minute
Specifications Dielectric Strength With Sensor Between G And Dc
50/60Hz 1,000VAC 1minute
Specifications Dimensions
120Ã120Ã38 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
13/11 W
Specifications Locked Rotor Current
0.16/0.15 A
Specifications Mass
550 g
Specifications Maximum Air Flow
1.55/1.75 m³/min | 54.8/ 60.8 ft³/min
Specifications Maximum Static Pressure
23.5/26.4 Pa | 0.094/0.106 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-30 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
1,800/2,000
Specifications Rated Voltage
100 V
Specifications Sensor Purpose Anode Lead Wire Color
Brown
Specifications Sensor Purpose Cathode Lead Wire Color
Black
Specifications Sensor Purpose Lead Wire Color
Yellow
Specifications Sound Pressure Level
30/32 dBA
