The San Ace 120 Series AC Fan with Sensor is a high-performance cooling solution designed for precision applications. With dimensions of 120x120x38 mm and a robust aluminum frame, this fan ensures efficient heat dissipation. The impeller, made of UL94V-1 rated plastics, guarantees safety and reliability. Operating at rated voltage of 100 V and drawing 7/6W input, it offers a maximum airflow of 1.5 m³/min. Its compliance with stringent dielectric strength and operating temperature range make it ideal for industrial and institutional settings, meeting the highest standards of quality and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Current
0.09/0.08 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between input terminal and frame)
Specifications Dielectric Strength With Sensor Between Ac Input
50/60 Hz 1,500 VAC 1 minute
Specifications Dielectric Strength With Sensor Between G And Dc
50/60Hz 1,000VAC 1minute
Specifications Dimensions
120Ã120Ã38 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
7/6 W
Specifications Locked Rotor Current
0.1/0.09 A
Specifications Mass
580 g
Specifications Maximum Air Flow
1.45/1.5 m³/min | 51/53 ft³/min
Specifications Maximum Static Pressure
17.7/17.7 Pa | 0.071/0.071 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-10 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
1,650/1,700
Specifications Rated Voltage
100 V
Specifications Sensor Purpose Anode Lead Wire Color
Brown
Specifications Sensor Purpose Cathode Lead Wire Color
Black
Specifications Sensor Purpose Lead Wire Color
Yellow
Specifications Sound Pressure Level
24/24 dBA
