San Ace 120T Wide Temp Range Fan, 24V
San Ace 120T Wide Temp Range Fan, 24V
SKU:SAN-5a671e
High-performance San Ace 120T Wide Temp Range Fan for extreme conditions. Voltage: 24V, RPM: 2900-5600, Airflow: 3.00-6.00 m³/min. Durable & reliable.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
San Ace 120T Wide Temp Range Fan, 24V
$39.99
Quantity: 1
Claim Your Seller Account
San Ace 120T Wide Temp Range Fan, 24V
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 9GT1224P1S001 San Ace 120T Wide Temperature Range Fan is precision-engineered for optimal performance in extreme conditions. With dimensions of 120 x 120 x 38mm and a sturdy aluminum frame, this fan operates at a rated voltage of 24V with a wide voltage range for versatile usage. It offers a PWM control feature for efficient speed regulation, ranging from 2900 to 5600 rpm. Designed to deliver consistent airflow of 3.00 to 6.00 m³/min and withstanding temperatures from -40 to +85 °C, this fan ensures reliable cooling in demanding environments. Built to last with an expected life of 40,000 hours, it complies with strict industry standards for maximum performance and durability.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black
Specifications Control Lead Wire Color
Brown
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 85c
40000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
420 g
Specifications Maximum Air Flow
6.00 m³/min | 211.8 ft³/min
Specifications Maximum Pulse Width Modulation Pwm Duty Cycle
100 %
Specifications Maximum Rated Current
1.1 A
Specifications Maximum Rated Input Power
26.4 W
Specifications Maximum Rated Speed
5600 rpm
Specifications Maximum Sound Pressure Level
58 dBA
Specifications Maximum Static Pressure
270 Pa | 1.08 inH2O
Specifications Minimum Air Flow
3.00 m³/min | 106.0 ft³/min
Specifications Minimum Pulse Width Modulation Pwm Duty Cycle
30 %
Specifications Minimum Rated Current
0.24 A
Specifications Minimum Rated Input Power
5.76 W
Specifications Minimum Rated Speed
2,900 rpm
Specifications Minimum Sound Pressure Level
41 dBA
Specifications Minimum Static Pressure
85.6 Pa | 0.34 inH2O
Specifications Non Condensing Storage Temperature
-40 to 85 ºC
Specifications Note
Fan does not rotate when Pulse-Width Modulation (PWM) duty cycle is 0%.
Specifications Operating Temperature Range
-40 to +85 ºC
Specifications Operating Voltage Range
18.0 to 27.6 V
Specifications Pulse Width Modulation Pwm Frequency
25 kHz
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
