San Ace 120W Series Splash Proof Fan
San Ace 120W Series Splash Proof Fan
SKU:SAN-317266
High-performance 120mm splash-proof fan for industrial applications, aluminum frame, UL94V-1 plastic impeller, 24V, 5200 rpm, 5.16 m³/min airflow, long lifespan.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
San Ace 120W Series Splash Proof Fan
$24.99
Quantity: 1
Claim Your Seller Account
San Ace 120W Series Splash Proof Fan
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 9WV1224P1H001 San Ace 120W Series Splash Proof Fan is a high-performance and durable cooling solution designed for industrial and institutional applications. With dimensions of 120 x 120 x 38 mm and a lightweight aluminum frame, this fan ensures efficient heat dissipation while maintaining a robust build quality. The fan features a UL94V-1 rated plastic impeller, providing both reliability and safety. Operating at 24V with a rated current of 0.80A, this fan offers a rated speed of 5200 rpm and an airflow of 5.16 m³/min, making it ideal for demanding cooling requirements. With an expected life of 60,000 hours at 60°C, this fan is built to deliver long-term performance in challenging environments.
Product Specifications
Specifications Air Flow
5.16 m³/min | 182 ft³/min
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black
Specifications Control Lead Wire Color
Brown
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
60,000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
440 g
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Note
Fan does not rotate when Pulse-Width Modulation (PWM) duty cycle is 0%.
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Pulse Width Modulation Pwm Duty Cycle
100 %
Specifications Pulse Width Modulation Pwm Frequency
25 kHz
Specifications Rated Current
0.80 A
Specifications Rated Input Power
19.2 W
Specifications Rated Speed
5200 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
58 dBA
Specifications Static Pressure
237 Pa | 0.95 inH2O
