San Ace 120W Series Splash Proof Fan, 120 x 120 x 38mm, 48V DC
San Ace 120W Series Splash Proof Fan, 120 x 120 x 38mm, 48V DC
SKU:SAN-f2e8fa
San Ace 120W Series Splash Proof Fan - Reliable cooling with durable materials. 48V, 2.80m³/min airflow.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 120W Series Splash Proof Fan, 120 x 120 x 38mm, 48V DC
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 120W Series Splash Proof Fan, 120 x 120 x 38mm, 48V DC
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 120W Series Splash Proof Fan is a durable and reliable cooling solution designed for demanding environments. With a frame made of aluminum and an impeller crafted from UL94V-1 rated plastics, this fan ensures both performance and safety. Operating at 48V with a rated current of 0.11A, it delivers a consistent airflow of 2.80 m³/min while maintaining a low sound pressure level of 39 dBA. Ideal for applications requiring stability and longevity, this fan boasts an expected life of 100,000 hours at 60°C.
Product Specifications
Specifications Air Flow
2.80 m³/min | 99 ft³/min
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
410 g
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
40.8 to 55.2 V
Specifications Rated Current
0.11 A
Specifications Rated Input Power
5.28 W
Specifications Rated Speed
2600 rpm
Specifications Rated Voltage
48 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
39 dBA
Specifications Static Pressure
70.4 Pa | 0.283 inH2O
