San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V

Name: San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V
Brand: Marsh Electronics, Inc.
SKU: SAN-5320c8
Price: 35.99 USD
Availability: OutOfStock

SKU:SAN-5320c8

San Ace 120W Series Splash Proof Fan - Premium cooling solution for demanding environments.

$35.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The San Ace 120W Series Splash Proof Fan is a robust cooling solution designed for demanding environments. With dimensions of 120 x 120 x 38 mm and a durable aluminum frame, this fan ensures reliable performance. The impeller is made of UL94V-1 rated plastics for enhanced safety. Operating at a voltage range of 14 to 27.6 V, this fan delivers efficient airflow of 2.80 m³/min and has a rated speed of 2600 rpm. It meets industry standards for sound pressure levels and has an expected life of 100,000 hours at 60°C, making it ideal for both consumer and institutional applications.

Product Specifications

Specifications Air Flow

2.80 mÂ³/min | 99 ftÂ³/min

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black | Blue

Specifications Dimensions

120 x 120 x 38 mm

Specifications Expected Life At 60c

100000 hours

Specifications Frame Material

Aluminum

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

410 g

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature Range

-20 to +70 ÂºC

Specifications Operating Voltage Range

14 to 27.6 V

Specifications Rated Current

0.22 A

Specifications Rated Input Power

5.28 W

Specifications Rated Speed

2600 rpm

Specifications Rated Voltage

24 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

39 dBA

Specifications Static Pressure

70.4 Pa | 0.283 inH2O

San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V
