San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V, UL94V-1
San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V, UL94V-1
SKU:SAN-8d4f43
Powerful and durable 120x120x38mm fan, 24V, UL94V-1 rated, ideal for demanding environments.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V, UL94V-1
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 120W Series Splash Proof Fan - 120x120x38mm, 24V, UL94V-1
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 120W Series Splash Proof Fan is a top-of-the-line cooling solution designed for both consumer and institutional buyers. With dimensions of 120 x 120 x 38 mm, this fan boasts a robust aluminum frame and a UL94V-1 rated plastic impeller for enhanced safety. Operating at 24V with a rated speed of 3,100 rpm, it delivers a powerful air flow of 3.34 m³/min while maintaining a low sound pressure level of 46 dBA. This fan is built to withstand a wide temperature range from -20 to +70 °C and has an expected life of 80,000 hours at 60 °C, making it perfect for demanding environments.
Product Specifications
Specifications Air Flow
3.34 m³/min | 118 ft³/min
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
80000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
410 g
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.34 A
Specifications Rated Input Power
8.16 W
Specifications Rated Speed
3,100 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
46 dBA
Specifications Static Pressure
100 Pa | 0.402 inH2O
