San Ace 120W Splash Proof Fan
San Ace 120W Splash Proof Fan
SKU:SAN-8f93a1
High-performance San Ace 120W Splash Proof Fan for industrial cooling needs. Durable construction for extended lifespan.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 120W Splash Proof Fan
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 120W Splash Proof Fan
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 120W Splash Proof Fan, model 9WG1248M101-E, is a reliable cooling solution designed for demanding environments. With a durable aluminum frame and UL94V-1 rated plastics impeller, this fan ensures high performance and safety. Operating at 48V with a rated speed of 1950 rpm, it delivers an airflow of 2.10 m³/min and has an expected life of 100,000 hours at 60ºC. Ideal for industrial and institutional applications requiring efficient cooling with low noise levels.
Product Specifications
Specifications Air Flow
2.10 m³/min | 74 ft³/min
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
410 g
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
40.8 to 55.2 V
Specifications Rated Current
0.07 A
Specifications Rated Input Power
3.36 W
Specifications Rated Speed
1950 rpm
Specifications Rated Voltage
48 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
32 dBA
Specifications Static Pressure
39.6 Pa | 0.159 inH2O
