San Ace 120W Splash Proof Fan 120 x 120 x 38 mm

Name: San Ace 120W Splash Proof Fan 120 x 120 x 38 mm
Brand: Marsh Electronics, Inc.
SKU: SAN-4fdad1
Price: 29.99 USD
Availability: OutOfStock

SKU:SAN-4fdad1

High-performance San Ace 120W Splash Proof Fan for industrial and commercial use. Durable construction for reliable cooling in challenging environments.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The San Ace 120W Series Splash Proof Fan is a high-performance cooling solution designed for industrial and commercial applications. With a durable aluminum frame and UL94V-1 rated plastic impeller, this fan offers reliable operation in challenging environments. Operating at a rated voltage of 24V, it provides efficient airflow of 2.45 m³/min and a static pressure of 54.2 Pa. This fan is built to last, with an expected lifespan of 100,000 hours at 60ºC, making it ideal for government and institutional procurement needs.

Product Specifications

Specifications Air Flow

2.45 mÂ³/min | 87 ftÂ³/min

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black | Blue

Specifications Dimensions

120 x 120 x 38 mm

Specifications Expected Life At 60c

100000 hours

Specifications Frame Material

Aluminum

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

410 g

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature Range

-20 to +70 ÂºC

Specifications Operating Voltage Range

14 to 27.6 V

Specifications Rated Current

0.16 A

Specifications Rated Input Power

3.84 W

Specifications Rated Speed

2280 rpm

Specifications Rated Voltage

24 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

36 dBA

Specifications Static Pressure

54.2 Pa | 0.218 inH2O
