San Ace 120W Splash Proof Fan - 120 x 120 x 38 mm

Name: San Ace 120W Splash Proof Fan - 120 x 120 x 38 mm
Brand: Marsh Electronics, Inc.
SKU: SAN-649df0
Price: 29.99 USD
Availability: OutOfStock

SKU:SAN-649df0

San Ace 120W Splash Proof Fan - Ultra-durable, high-performance 120x120x38 mm cooling fan for industrial and institutional use.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The San Ace 120W Splash Proof Fan is a reliable cooling solution designed for industrial and institutional environments. With a durable plastic frame and UL94V-0 flammability rating, this fan ensures safety and longevity. Operating at 12V with a rated current of 0.38A, it delivers optimal airflow of 2.80 m³/min at 2600 rpm. Meeting stringent industry standards, including non-condensing storage temperatures from -30 to +70 ºC and an expected life of 40,000 hours at 60ºC, this fan is ideal for government and institutional procurement needs.

Product Specifications

Specifications Air Flow

2.80 mÂ³/min | 99 ftÂ³/min

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black

Specifications Dimensions

120 x 120 x 38 mm

Specifications Expected Life At 60c

40,000 hours

Specifications Frame Material

Plastics (Flammability: UL94V-0)

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

360 g

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature Range

-20 to +70 ÂºC

Specifications Operating Voltage Range

7.0 to 13.8 V

Specifications Rated Current

0.38 A

Specifications Rated Input Power

4.56 W

Specifications Rated Speed

2600 rpm

Specifications Rated Voltage

12 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

39 dBA

Specifications Static Pressure

70.4 Pa | 0.283 inH2O

San Ace 120W Splash Proof Fan - 120 x 120 x 38 mm
