San Ace 120W Splash Proof Fan - 120x120x38mm, 24V DC
San Ace 120W Splash Proof Fan - 120x120x38mm, 24V DC
SKU:SAN-72ac99
San Ace 120W Splash Proof Fan - Efficient cooling, durable design, PWM controllable
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
San Ace 120W Splash Proof Fan - 120x120x38mm, 24V DC
$39.99
Quantity: 1
Claim Your Seller Account
San Ace 120W Splash Proof Fan - 120x120x38mm, 24V DC
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 120W Series Splash Proof Fan is a robust cooling solution designed for demanding environments. With a frame made of durable aluminum and a flame-retardant plastic impeller, this fan ensures efficient cooling with a maximum air flow of 6.35 m³/min. Operating at 24V DC within a temperature range of -20 to +70°C, it offers reliability with a 60,000-hour lifespan at 60°C. This fan is PWM controllable and meets stringent industry standards for safety and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black
Specifications Control Lead Wire Color
Brown
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
60,000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
440 g
Specifications Maximum Air Flow
6.35 m³/min | 224.0 ft³/min
Specifications Maximum Rated Current
1.50 A
Specifications Maximum Rated Input Power
36 W
Specifications Maximum Rated Speed
6400 rpm
Specifications Maximum Sound Pressure Level
64 dBA
Specifications Maximum Static Pressure
360 Pa | 1.45 inH2O
Specifications Minimum Air Flow
1.49 m³/min | 52.6 ft³/min
Specifications Minimum Rated Current
0.12 A
Specifications Minimum Rated Input Power
2.88 W
Specifications Minimum Rated Speed
1500 rpm
Specifications Minimum Sound Pressure Level
33 dBA
Specifications Minimum Static Pressure
26.1 Pa | 0.105 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Note
Fan does not rotate when Pulse-Width Modulation (PWM) duty cycle is 0%.
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Pulse Width Modulation Pwm Duty Cycle
100 %
Specifications Pulse Width Modulation Pwm Frequency
25 kHz
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
