The San Ace 120W Splash Proof Fan 48V is a high-performance cooling solution designed to meet the rigorous requirements of both consumer and institutional buyers. With dimensions of 120 x 120 x 38 mm and a lightweight yet durable frame made of UL94V-0 plastics, this fan ensures reliable operation in various environments. Its UL94V-1 plastics impeller, rated voltage of 48 V, and wide operating voltage range of 40.8 to 55.2 V make it versatile for different applications. Boasting a rated speed of 2600 rpm and robust airflow of 2.80 m³/min, this fan delivers efficient cooling while maintaining a low sound pressure level of 39 dBA. With an expected life of 40,000 hours at 60°C, the San Ace 120W Splash Proof Fan 48V is a dependable choice for demanding cooling needs.
Product Specifications
Specifications Air Flow
2.80 m³/min | 99 ft³/min
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
40,000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
360 g
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
40.8 to 55.2 V
Specifications Rated Current
0.11 A
Specifications Rated Input Power
5.28 W
Specifications Rated Speed
2600 rpm
Specifications Rated Voltage
48 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
39 dBA
Specifications Static Pressure
70.4 Pa | 0.283 inH2O
